D4 equalizer bar

Your tractor will never be Bud Droopy again.
[attachment=70956]download.jpg[/attachment]

Hi, Jimmy977.
The equalizer springs went the way of the dinosaurs back in the 1950s and '60s. Since then, solid equalizer bars have been 'the go'. with rubber pads under them.

Hi, ROME K/G.
Unless said equalizer bar breaks - - - in which case there will a SEVERE droop. And I have seen broken equalizer bars in D10s and D11s. Quite a let-down.

Just my 0.02.

Ok thanks.  I have a parts cable operated d4 7u loader, serial number approximately 350. I'm thinking about the 5 roller track roller frame swap to a 7u d4 bulldozer.

Hi, Jimmy977.
I don't know if they will switch straight over as I think the track frames on the loader would be rigid mounted but they may possibly still have the equalizer spring too. I just don't know.

There may also be an issue with the sway braces on the blade with the longer track frames. Again, I don't know for sure but suggest that you do your homework.

Just my 0.02.

The track frames are solid mounted. I do believe there will be clearance issues as Deas has said with the dozer frame.

Hi, kracked1.
If my memory serves me right, the back end of the track frames are the same, complete with diagonal brace and outer bearing. What I don't know but strongly suspect whether the rigid mounting on the loader track frames is in the same place where the equalizer spring pockets would be. If that is the case, then he would need to cut off the rigid mountings and fabricate the pockets for the equalizer spring - or bar.

Just my 0.02.

I was also planning on swapping or modifications to c- frame for clearance of longer track frame. I see the old holt manufacturing c-frames look like they have more clearance in front of track frame.

I dont know if the D2 rigid frame is similar to the D4, but on a D2 traxcavater parts machine that I have the oil pan is different than on regular D2 crawler. You might want to check and see if that also applies to a D4. Just a thought. Grant.
