17a brake band installation

You have to loosed the screw adjustement band under the cluch housing

Did that.still not enough room

I am not sure but when we instaled some brakes in my D7 we had to instaled the 2 front bands togeter and we turning them in front and we instaled the 3 band

That's how I installed it.rotated the front two and connected the rear band.vut the rear band studs will not pass under the drum.

If your 3 band are bolted togetter the studs should not be in bottom and did you instaled all the parts on anchor and am not sure but should have more 1 inch under drum and housing it ben 40 years I did not tuch these dozers

If your 3 band are bolted togetter the studs should not be in bottom and did you instaled all the parts on anchor and am not sure but should have more 1 inch under drum and housing it ben 40 years I did not tuch these dozers

It's been a long time since I did brakes like this, but I think Hector is telling you the studs don't go under the drum they stay on the back side.
Hook up the anchor plate and you will see this.
Bob

The studs point down.so did the old ones.my hand won't fit under the drum all the way its a tight fit.

It's been a long time since I did brakes like this, but I think Hector is telling you the studs don't go under the drum they stay on the back side.
Hook up the anchor plate and you will see this.
Bob
